Simplest, easiest to use direct modeler with compatibility to all other mainstream CAD tools

Kommentare: The most 'non obvious' benefit was the ability to import a CAD file from multiple sources and save back out as a JT file in different JT standard release formats. This is FAR simpler than using many of the various translation tools we have to translate from CAD to a neutral format to JT.

Vorteile:

SpaceClaim is so easy to use, even a lowly manager with no recent design experience can utilize it to produce rudimentary designs in record time. Direct modeling, and the ability to import from a wide range of CAD tools, as well as export in many of those same formats, makes reuse of existing designs a snap. With four basic sets of commands, almost anything you can imagine can be layed out in at least a preliminary state for your 'real' designers to complete using the tool of their choice. Or better yet, they can use SpaceClaim to finish the design in an extremely short time.

Nachteile:

The interface and command set is so simple, I always feel like I am missing something. If you can't think in 3D, this my not be the tool for you. Drafting is NOT a strong suit, because SpaceClaim is all about design.

For Designers

Vorteile:

Direct Modeling, Easy of use. Part programming and automation

Nachteile:

There is not fundamental cons. Some functionalities need improvents like drawting etc

Spaceclaim Review

Kommentare: Overall, the software is good but I prefer other software with better assembly features.

Vorteile:

I like that this software has features that allows for easy deletion of model parts. With other modeling software I have used in the past, problems arise when a component is changed or deleted. This software does not have this issue because it is not as strict. It is user friendly and easy to learn.

Nachteile:

I don't like certain aspects of this software, the mating in the assembly section is sub-par. I also do not like that you have to undo a bunch of steps to change a component of the part being modeled.

Direct Editing 3D Software

Kommentare: This software allows you to import virtually any CAD file into your CAD system, whether it was created in your CAD program or not. You can make changes, create drawings and export the revised file in the native format you need. Having the capability to modify any CAD file is huge! Can you imagine the time savings? Don't think of it as a replacement CAD software that you have to learn, think of it as an added tool which allows quick and accurate modifications to CAD files. We use this software in our service bureau because of the time efficiency for creating STL files for 3D printing. You can't beat the time savings of 50%!

Vorteile:

Ease of use

Nachteile:

Can't really think of any cons on the software itself. The only thing I would say is that you have to purchase the software license along with additional modules which allow for various native file formats to be exported.

Easy to Use - Great Functionality

Kommentare: I use SpaceClaim to design everything from simple plastic parts to highly complex mechanical systems. I still consider myself an intermediate user as there is much functionality that I have yet to utilize.

Vorteile:

I use SpaceClaim because it has a simple user interface and performs almost every function you may need in a Mechanical 3D CAD tool. The learning curve on this software is very short when compared to SolidWorks.

Nachteile:

Some things are a little difficult to do in SpaceClaim. For example editing of curved surfaces and other none uniform surfaces can be tricky.
